MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1 Log 1 (SRV2546-711) +$104.07
QTY: 2 Log 2 (SRV2546-712) +$106.86
QTY: 3 Log 3 (SRV2546-713) +$106.86
QTY: 4 Log 4 (SRV2542-718) +$118.04
QTY: 5 Log 5 (SRV2542-718) +$118.04
QTY: 6 Log 6 (SRV2542-717) +$118.04
QTY: 7 Side Plate (2532-014) +$94.28
QTY: 7A Slide Plate Tool (2532-140) +$20.18
QTY: 7B Slide Plate Gasket (2532-113) +$12.84
QTY: 8 Top Glass Clip [2 per unit, each sold separately] (2155-046) +$20.18
QTY: 9 Baffle (2532-138) +$144.59
QTY: 10 Bottom Glass Clip [2 per unit, each sold separately] (2532-009) +$49.86
QTY: 11 Air Scoop (2532-135) +$35.96
QTY: 12 Pilot Shield (2532-153) +$31.55
QTY: 13 Burner (2546-007) +$256.04
QTY: 14 Base Pan (2546-130) +$213.17
QTY: 15 Glass Frame Seal (2532-122) +$62.29
QTY: 16 Glass Door (GLA-2532) +$865.65
QTY: 17 Power Cord (2201-017) +$137.61
QTY: 33 Complete Log Set (LOGS-2546) +$304.27
VALVE ASSEMBLY
Item Description (Part Number)
QTY: 18 Pilot Assembly NG [recommend using High Temperature Red Silicone and replacing Gasket](2550-013) +$97.08
QTY: 18A Pilot Assembly LP [recommend using High Temperature Red Silicone and replacing Gasket](2550-014) +$97.08
QTY: 18B High Temperature Red Silicone (70AW) +$18.33
QTY: 19 Pilot Gasket (2532-134) +$11.38
QTY: 20 Flex Ball Valve Assembly (2532-081) +$98.48
QTY: 21 Valve NG (750-500) +$168.95
QTY: 21A Valve LP (2155-501) +$270.78
QTY: 22 Male Connector [package of 5] (303-315/5) +$47.07
QTY: 23 Valve Plate Gasket (2532-131) +$28.62
QTY: 24 Bulkhead Gasket (438-407) +$11.38
QTY: 25 Bulkhead with Flex Tube (SRV7000-156) +$80.31
ITEMS NOT SHOWN - VALVE ASSEMBLY
Item Description (Part Number)
QTY: 34 Orifice #37C NG (582-837) +$38.93
QTY: 35 Orifice #52C LP (SRV582-852) +$38.93
COMPONENT TRAY
Item Description (Part Number)
QTY: 26 Component Heat Shield (2541-144) +$37.43
QTY: 27 IPI Control Module ~Old Part # 593-592~ (SRV593-592) +$120.84
QTY: 28 Wire Assembly (SRV593-590) +$45.67
QTY: 29 3V Transformer (SRV593-593) +$34.49
QTY: 30 Remote Wire Assembly (2103-013) +$52.66
QTY: 31 Wire Tray (2534-171) +$48.46
QTY: 32 Component Tray (2534-170) +$45.67
Accessories
Item Description (Part Number)
QTY: 36 Battery Pack (SRV593-594) +$15.78
QTY: 37 Fan (GFK-160A) +$319.00
QTY: 38 Leg Level Bolt [4 per unit, each sold separately] (2073-162/24) +$78.91
QTY: 39 Lava Rock (4021-296) +$20.18
QTY: 40 Mineral Wool (050-721) +$11.38
QTY: 41 PEM Plate Assembly (2532-013) +$28.62
QTY: 42 PEM Plate Gasket (2532-150) +$12.84
QTY: 43 Remote (SMARThermostat-MAJ) +$239.00
QTY: 44 Bottom Glass Clip Screw [4 per unit, each sold separately] (419-802/24) +$33.02
QTY: 45 Touch-Up Paint (TUP-GBK-12) +$55.45
QTY: 46 Conversion Kit [NG to LP] (NGK-MI-IPI) +$Call to Order
QTY: 47 Conversion Kit [LP to NG] (LPK-MI-IPI) *No Longer Available* +$*0.00*
QTY: 48 Pilot Orifice NG (SRV593-528) +$38.93
QTY: 49 Pilot Orifice LP (593-526) +$18.71
QTY: 50 Regulator NG (SRVNGK-DXV) +$113.85
QTY: 51 Regulator LP (SRVLPK-DXV) +$113.85
QTY: 52 Owners Manual [hard copy] [2546-981] (OMHC-VC) +$9.99
QTY: 53 Owners Manual [electronic copy] [2546-981] (OMEL-VC) +$0.00
|
