Includes models: 43BDVRRN NG Millivolt, 43BDVRRP LP Millivolt, 43BDVREN NG 24V, 43BDVREP LP 24V
SERIES D12, D13, D14
MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1 Complete Log Set (10003696) *No Longer Available* +$*0.00*
QTY: 1A Front Left Log (BD12) *No Longer Available* +$*0.00*
QTY: 1B Front Right Log (BD14) *No Longer Available* +$*0.00*
QTY: 1C Rear Log (BD11) *No Longer Available* +$*0.00*
QTY: 1D Top Center Log (BD13) *No Longer Available* +$*0.00*
QTY: 1I Black Lava Rock ~Old Part #s 10001454, 00F0540~ (SRV00F0540) +$63.46
QTY: 1J Embers ~Old Part # 51915~ (58D0443) +$32.92
QTY: 2A Burner Housing Assembly NG (10003649) *No Longer Available* +$*0.00*
QTY: 2B Burner Housing Assembly LP (10003649) *No Longer Available* +$*0.00*
QTY: 2C Ceramic Tile [4 per unit, each sold separately][recommend replacing a new Gasket. the Gasket will Need to be custom cut. Gasket Part #CFPAP 1/2-48-65-1.] ~Old Part # 57803~ (SRV57803) +$51.60
QTY: 2D Ceramic Tile Gasket (CFPAP1/8-48-65-1) +$17.50
QTY: 3B 3-Way Top Convertible Pilot Assembly SIT RP LP [includes: Thermopile, Thermocouple, Pilot, Pilot Tube and Electrode] [recommend using High Temperature Red Silicone] ~Old Part # 10002265~ (SRV10002265) +$177.95
QTY: 4B Pilot Assembly 3-Way Top Convertible EN LP [recommend using High Temperature Red Silicone] (10002388)*No Longer Available* [can Sub (1) 10002387 together with (1) SRV200-2630] +$*0.00*
QTY: 5 Pilot Bracket Top Convertible (10002266) *No Longer Available* [can Sub SRV10002264-NG or SRV10002265-LP] +$*0.00*
QTY: 6 SIT Top Convertible Pilot Hood (10002385) +$42.38
QTY: 9B Flexible Gas Line with On/Off Valve ~Old Part # 20002500~ (SRV20002500) +$92.67
QTY: 10A Cable Igniter [EN, EP] (10000696) *No Longer Available* [can sub Electrode Igniter with Cable 10001297] +$*0.00*
QTY: 14A SIT Electronic Gas Valve NG (57884) +$593.18
QTY: 14B SIT Electronic Gas Valve LP ~Old Part # 57883~ (37D0017) *No Longer Available* +$*0.00*
QTY: 14C Sensing Electrode with Cable [EN, LP] (57885) +$48.93
QTY: 15 Transformer [EN, EP] ~Old Part #s 7522409, 022788~ (SRV022788) +$305.72
QTY: 16 Honeywell Ignition Module [EN, EP] (20000005) *No Longer Available* +$*0.00*
QTY: 16A Honeywell Wire Harness [EN, EP] (10001979) +$Call to Order
QTY: 17B Fan Temperature Sensor ~Old Part # 51704~ (SRV51704) +$63.46
QTY: 17C Fan Speed Control ~Old Part # 51738~ (SRV51738) +$111.34
QTY: 17D Fan Speed Control Knob [Black] (51882) +$37.95
QTY: 18 Fan Only with Cord ~Old Part # ZA1110~ (FK12) +$381.05
QTY: 19 Window Frame (10001805) *No Longer Available* +$*0.00*
QTY: 19B Glass Only [Glass Gasket sold separately] (57438) +$908.95
QTY: 19C Glass Gasket ~Old Part #s 57317, 10000992K~ (10000992K/12) +$149.94
QTY: 20 Window Frame Clamp (54174) *No Longer Available* +$*0.00*
QTY: 21 Polished Brass Window Trim with Magnets [2 per unit, each sold separately] (57485) *No Longer Available* +$*0.00*
QTY: 22 Top Louver (10000041) *No Longer Available* +$*0.00*
QTY: 23 Bottom Louver (10000042) *No Longer Available* +$*0.00*
QTY: 24 Hinge [for Bottom Louver] (52356) *No Longer Available* +$*0.00*
QTY: 25 Support Center Log with Stub (10003383) *No Longer Available* +$*0.00*
QTY: 26 Relief Plate wihth Gasket ~Old Part # 10004192~ (10004192K) +$168.21
Accessories
Item Description (Part Number)
QTY: 27 Remote On/Off Switch (51842) +$48.29
QTY: 29 Deflector Top (54655) +$Call to Order
QTY: 30 Owners Manual [hard copy] [10003357] (OMHC-VC) +$9.99
QTY: 31 Owners Manual [electronic copy] [10003357] (OMEL-VC) +$0.00
|
