Includes Models: 0002235 Classic Black, 0002236 Biscuit, 0002237 Majolica Brown, 0002238 Bordeaux, 0002239 Twilight
Beginning Manufacturing Date is May 2020
MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1 Griddle with Brackets (SRV1-10-586134) +$524.00
QTY: 1A Griddle Bracket [includes Left, Right Brackets with dowel Pins and Retainers] (SRV3000731) +$160.90
QTY: 1B Dowl Pin [2 per unit, each sold separately] (30007368) +$27.35
QTY: 1C Griddle (4-00-586134A) +$313.84
QTY: 1D Griddle Handle (1-00-586170) +$199.88
QTY: 1E Griddle Knob (1600661) +$11.68
QTY: 2 Top [Classic Black] (4-00-586135A) +$406.64
QTY: 2A Top [Biscuit] (4-00-586135-32A) +$714.00
QTY: 2B Top [Majolica Brown] (4-00-586135-31A) +$674.00
QTY: 2C Top [Bordeaux] (4-00-586135-33A) +$804.00
QTY: 2D Top [Twilight] (4-00-586135-30A) +$554.00
QTY: 2E Top Gasket [15 ft per package] (1-00-30002422) +$64.25
QTY: 3 Damper Cover Rod (SRV2-00-586191) +$104.77
QTY: 4 Damper Steel Handle with Set Screw (30002720A) +$88.25
QTY: 6 Phillips Head [each sold separately] (1201310) +$15.06
QTY: 7 Damper Rod (SRV3-40-586164) +$227.89
QTY: 7A Damper Adjuster (SRV2-00-586201) +$100.96
QTY: 7B Damper Plate and Rod Repair Kit (SRV8787-019) +$337.04
QTY: 8 Damper Shaft Retainer [set of 2] (SRV2-00-586186) +$104.77
QTY: 9 Damper Frame (4-00-586184A) +$267.44
QTY: 9B Outside Damper Frame Gasket [15 ft per package] (1-00-30002422) +$64.25
QTY: 10 Damper Plate (4-00-586200A) +$203.53
QTY: 10A Hex Head [each sold separately] (1201337) +$11.18
QTY: 10B Screw [each sold separately] (1201338) +$12.65
QTY: 10C Screw [each sold separately] (1201376) +$11.18
QTY: 10E Screw [Fastener for Damper Assembly to Back Casting] [each sold separately] (1201376) +$11.18
QTY: 10F Flat Washer [Fastener for Damper Assembly to Back Casting] [each sold separately] (1202470) +$12.26
QTY: 10G Hex Nut [Fastener for Damper Assembly to Back Casting] [each sold separately] (1203210) +$11.18
QTY: 11 Left Side [Classic Black] (4-00-586123A) +$444.00
QTY: 11A Left Side [Biscuit] (4-00-586123-32A) +$714.00
QTY: 11B Left Side [Majolica Brown] (4-00-586123-31A) +$714.00
QTY: 11C Left Side [Bordeaux] (4-00-586123-33A) +$724.00
QTY: 11D Left Side [Twilight] (4-00-586123-30A) +$604.00
QTY: 11E Leveler Bolt [each sold separately] (1201745) +$27.32
QTY: 11F Gasket for Side of Stove [15 ft per package] (1-00-30002422) +$64.25
QTY: 11G Mobile Home Bracket [set of 2] (SRV586189) +$46.60
QTY: 12 Front Handle Holder (SRV2-00-586197) +$81.90
QTY: 13 Ash Grate (3-00-586122A) +$163.34
QTY: 14 Air Control Baffle (SRV2-00-586148) +$120.02
QTY: 15 Ash Pan (30007339) +$159.68
QTY: 15A Ash Pan Lid (30007339-B) +$62.25
QTY: 16 Front [Classic Black] (4-00-586121A) +$429.84
QTY: 16A Front [Biscuit] (4-00-586121-32A) +$724.00
QTY: 16B Front [Majolica Brown] (4-00-586121-31A) +$724.00
QTY: 16C Front [Bordeaux] (4-00-586121-33A) +$724.00
QTY: 16D Front [Twilight] (4-00-586121-30A) +$584.00
QTY: 16E Gasket for Front of Stove [15 ft per package] (1-00-30002422) +$64.25
QTY: 17 Andiron [2 per unit, each sold separately] (3-00-586128A) +$81.90
QTY: 18 Andiron Mounting Plate [2 per unit, each sold separately] (SRV2-00-586169) +$44.06
QTY: 18A Hex Head [2 per unit, each sold separately] (1201337) +$11.18
QTY: 19 Ash Lip [Classic Black] (3-00-586144A) +$227.89
QTY: 19A Ash Lip [Biscuit] (3-00-586144-32A) +$406.64
QTY: 19B Ash Lip [Majolica Brown] (3-00-586144-31A) +$406.64
QTY: 19C Ash Lip [Bordeaux] (3-00-586144-33A) +$406.64
QTY: 19D Ash Lip [Twilight] (3-00-586144-30A) +$418.24
QTY: 19E Screw [each sold separately] (1200998) +$11.18
QTY: 20 Glass Clips [set of 4 per Door] [2 Sets per unit, each Set sold separately] (SRV2-00-586207) +$76.82
QTY: 20A Glass Clip Screw [8 per unit, each sold separately] (1200980) +$11.18
QTY: 21 Load Door Glass [2 per unit, each sold separately] (SRV3-40-586138) +$159.68
QTY: 21A Load Door Glass Gasket [10 ft per package] (1-00-1186258229) +$28.69
QTY: 22 Left & Right Door Hinge Set [2 per unit, each sold separately] (SRV2-00-586204) +$383.44
QTY: 23 Door Pin [4 per unit, each sold separately] (30002727) +$10.95
QTY: 24 Hinge Clamp Plate [2 per unit, each sold separately] (SRV2-00-586205) +$49.14
QTY: 25 Left Door [Classic Black] (4-00-586126A) +$302.24
QTY: 25A Left Door [Biscuit] (4-00-586126-32A) +$444.00
QTY: 25B Left Door [Majolica Brown] (4-00-586126-31A) +$434.00
QTY: 25C Left Door [Bordeaux] (4-00-586126-33A) +$564.00
QTY: 25D Left Door [Twilight] (4-00-586126-30A) +$418.24
QTY: 25G Gasket Glue (77) +$11.18
QTY: 26 Black Wood Handle with Lifter [includes: Black Handle, Screw & Nickel nub] (30004175K) +$73.01
QTY: 26B Damper Handle Screw [each sold separately] (1201310) +$15.06
QTY: 26C Insert Lifter (30002714) +$30.02
QTY: 26D White Ceramic Handle with Screw & Insert (0004342) +$101.43
QTY: 26E Stainless Steel Socket for Handle (1200334) +$10.95
QTY: 27 Front Door Latch Assembly (SRV1-10-586145) +$141.61
QTY: 27A Front Steel Handle/Shaft (30002717) +$80.63
QTY: 27B Spring Washer [each sold separately] (63D0069) +$11.18
QTY: 27C Pawl Assembly (30005157) +$49.14
QTY: 27D Flat Washer [each sold separately] (1202560) +$12.26
QTY: 27E Jam Nut [each sold separately] (1203290) +$11.18
QTY: 28 Right Door [Classic Black] (4-00-586127A) +$290.64
QTY: 28A Right Door [Biscuit] (4-00-586127-32A) +$454.00
QTY: 28B Right Door [Majolica Brown] (4-00-586127-31A) +$454.00
QTY: 28C Right Door [Bordeaux] (4-00-586127-33A) +$464.00
QTY: 28D Right Door [Twilight] (4-00-586127-30A) +$429.84
QTY: 28G Gasket Glue (77) +$11.18
QTY: 29 Bottom Heat Shield (SRV2-00-586165) +$127.64
QTY: 30 Ashdoor Lower Mount Bracket (SRV2-00-586143) +$56.63
QTY: 30A Washer [each sold separately] (7000-579) +$Call to Order
QTY: 30B Screw [each sold separately] (1201374) +$11.18
QTY: 31 Ashdoor (4-00-586206A) +$264.43
QTY: 32 Ashdoor Handle Assembly (SRV1-10-1600663) +$135.26
QTY: 32A Ashdoor Handle [Black, Hardwood] (1600663) +$11.68
QTY: 32B Handle Shaft (30005301) +$98.42
QTY: 32C Spring Washer [each sold separately] (63D0069) +$11.18
QTY: 32D Flat Washer [each sold separately] (1202560) +$12.26
QTY: 32E Pawl Assembly (30005157) +$49.14
QTY: 32F Jam Nut [each sold separately] (1203290) +$11.18
QTY: 33 Ash Pan Bracket (30007376A) +$56.63
QTY: 34 Ashdoor Upper Mount (SRV2-00-586142) +$49.14
QTY: 35 Bottom Air Cover (SRV2-00-586147) +$157.25
QTY: 36 Air Control (SRV1-10-586156) +$267.44
QTY: 37 Left Brick Clip (SRV2-00-586193) +$81.90
QTY: 38 Right Brick Clip (SRV2-00-586194) +$81.90
QTY: 39 Refractory Gasket (SRV3-44-586168) +$79.36
QTY: 40 Refractory Access Cover (SRV3-40-586152) +$279.04
QTY: 41 Firebrick [9-3/4 Inches X 3-1/2 Inches X 1-1/4 Inch] [4 per unit, each sold separately] (SRV2-00-586192) +$123.83
QTY: 42 Fiberfax Insulation (SRV3-44-586196) +$114.93
QTY: 43 Rear Brick Clip [2 per unit, each sold separately] (SRV2-00-586153) +$92.06
QTY: 44 Stainless Steel Fireback Plate (SRV2-00-586188) +$108.58
QTY: 45 Refractory Fireback (SRV3-40-586151) +$669.90
QTY: 43 Refractory Engine (30007299A) +$585.90
QTY: 43A Hex Head [each sold separately] (1201337) +$11.18
QTY: 43B Hex Head [each sold separately] (1201372) +$11.18
QTY: 47 Right Side [Classic Black] (4-00-586124A) +$474.00
QTY: 47A Right Side [Biscuit] (4-00-586124-32A) +$724.00
QTY: 47B Right Side [Majolica Brown] (4-00-586124-31A) +$794.00
QTY: 47C Right Side [Bordeaux] (4-00-586124-33A) +$744.00
QTY: 47D Right Side [Twilight] (4-00-586124-30A) +$604.00
QTY: 47E Leveler Bolt [each sold separately] (1201745) +$27.32
QTY: 47F Side Gasket [15 ft per package] (1-00-30002422) +$64.25
QTY: 47G Mobile Home Bracket [set of 2] (SRV586189) +$46.60
QTY: 48 Ball Plunger (3-31-5500) +$Call to Order
QTY: 49 Primary Air Control Handle Assembly [Black, Maple] (SRV1-10-586149) +$55.36
QTY: 49A Thermostat Knob [Black, Maple] (1600660) +$11.68
QTY: 49B Round Head [each sold separately] (1202560) +$12.26
QTY: 50 Thermostat Stub with Set Screw (30002716) +$42.79
QTY: 50A Thermostat Cable [contains 2 copper Sleeves] (SRV30007519) +$45.33
QTY: 51 Air Control (SRV1-10-1601430) +$131.45
QTY: 52 Air Control Wheel (SRV2-00-586163) +$46.60
QTY: 53 Outside Air Box (SRV1-10-586161) +$184.04
QTY: 54 Rear Housing (4-00-586129A) +$476.24
QTY: 54A Side Opening Gasket [15 ft per package] (1-00-30002422) +$64.25
QTY: 54B Refractory Opening Gasket [15 ft per package] (1-00-30001910) +$79.36
QTY: 55 Back Insulation Board (SRV3-44-586183) +$133.99
QTY: 56 Rear Air Jacket (SRV2-00-586177) +$290.64
QTY: 57 Rear Vent Rear Cover Heat Shield (SRV2-00-586175) +$107.31
QTY: 58 Air Inlet (SRV2-00-586173) +$114.93
QTY: 59 Exhaust Diverter (SRV2-00-586182) +$93.33
QTY: 60 6 Inch Flue Collar [Classic Black] (4-00-250102A) +$215.71
QTY: 60A Flue Collar Gasket [15 ft per package] (1-00-30002422) +$64.25
QTY: 61 Top Vent Cover Heat Shield (SRV2-00-586176) +$118.74
QTY: 62 Heat Shield Common (SRV2-00-586174) +$140.34
ITEMS NOT SHOWN - MAIN ASSEMBLY
Item Description (Part Number)
QTY: 63 Finish Bag (SRV1-00-586209) +$252.25
QTY: 64 Touch-Up Paint (3-42-19905) +$38.98
QTY: 66 Catalyst Ceramic (SRV8340-006) +$337.04
QTY: 70 Stove SurFace Thermometer (0000574) +$81.90
QTY: 72 Owners Manual [hard copy] [3-90-58600] (OMHC-VC) +$9.99
QTY: 73 Owners Manual [electronic copy] [3-90-58600] (OMEL-VC) +$0.00
|
