Dutchwest Seneca Stove (2169-2170)

QTY: 1-Bottom ~Old Part #1306035~ (1306035A) +$295.28

QTY: 2-Back ~Old Part #1306045~ (1306045A) +$323.12

QTY: 3-Inner Bottom (1306036) +$226.80

QTY: 4-Inner Back (1306038) +$159.38

QTY: 5-Inner Top with Web Assembly (0000007) +$480.88

QTY: 6-Air Valve (1606055) +$18.21

QTY: 7-Brass Ball (1602470) +$13.03

QTY: 8-Air Tube (1306041) +$110.91

QTY: 9-Baffle ~Old Part #7000953~ (7000953A) +$139.36

QTY: 9A Baffle Hardware Kit (7000953H) +$33.55

QTY: 10-Inner Top Channel (1306042) +$76.72

QTY: 11-S. S. Air Distributor [Oval] (7000952) +$78.09

QTY: 12 Catalyst [Combustor] ~Old Part #000CB56~ (SRV50001038) +$615.00

QTY: 13-Interam Gasket Kit [for Catalytic Combustor] ~Old Part #1203533~ (1203533A) +$32.92

QTY: 14 Right Side ~Old Part #1306037~ (1306037A) +$224.24

QTY: 15 Left Side ~Old Part #1306043~ (1306043A) +$260.78

QTY: 16-Side Door Hinge Plate (700G808) +$45.12

QTY: 17-Side Door (1306044) +$151.93

QTY: 18 Front Door ~Old Part #1306046~ (1306046A) +$408.96

QTY: 19-Front Door ~Old Part #1306047~ (1306047A) +$225.46

QTY: 20-Gasket [Side Door, Front Door & Ash Pan Door 15 FT PKG] (1-00-1203589) +$52.93

QTY: 21-Front Hinge (1606057) +$34.03

QTY: 22-Door Handle Gold with Shaft (5004271) +$98.25

QTY: 23-Door Latch with Set Screw (0000836) +$124.68

QTY: 23A-Socket Set Screw [includes ABOVE] (1200563) +$14.95

QTY: 25-Glass 13.47 Inches X 7.96 Inches (1606058) +$241.77

QTY: 26-Glass Retainer Clip (1601396) *No Longer Available* +$*0.00*

QTY: 26A-Clip Screw [4 per unit, each sold separately] (1200980) +$11.95

QTY: 27-Brass Trim Glass (1406060) *No Longer Available* +$*0.00*

QTY: 28-By-Pass Gate [Damper] [Hardware Kit sold separately] ~Old Part #7000954~ (7000954A) +$96.67

QTY: 28A-By-Pass Gate Hardware Kit [Damper] (7000954H) +$48.93

QTY: 29-By-Pass Adjuster ~Old Part #7000950~ (7000950A) +$103.34

QTY: 29A Damper Adjuster Hardware Kit (7000950H) +$18.88

QTY: Catalytic Probe [2_BDIN] ~Old Part #7000948~ (7000948A) +$126.02

QTY: Insert Handle Lifter Gold (1600651) +$34.76

QTY: White Ceramic Handle [can Sub Maple Wood /Black Handle 1600664] (1600620) *No Longer Available* +$*0.00*

QTY: Maple Wood Black Handle (1600664) +$12.47

QTY: OV HD Slot 1/4 -20 X 3 (1201293) +$19.95

QTY: Fallaway Handle [ITEMS 31 32 33] (0005854) +$99.16

QTY: Front Door Handle Assembly [includes: Fallaway Handle, Faucet Stub with Shaft, Pawl Assembly & Jam Nut] (0004240) +$208.68

QTY: 34-Damper Tab (1601488) +$11.18

QTY: 35-By-Pass Crank (7000951) +$70.13

QTY: 36-Glass Gasket [10ft per package] ~Old Part #1203556~ (1-00-1186258229) +$34.32

QTY: Ashdoor Red (1316057) +$Call to Order

QTY: 38-Ashdoor Hinge Pin 5 Inches (1206061) +$11.03

QTY: 40-By-Pass Gate Operating Rod (7001145) +$36.43

QTY: Primary Air Rod (1606056) +$Call to Order

QTY: Friction Spring (1201846) +$12.95

QTY: Thermostat Stub with Set Screw (5004263) +$43.60

QTY: 44-Flat Grate (1306050) +$127.32

QTY: Wood Thermostat Handle Knob (1600660) +$12.47

QTY: 46-Grate Back 171/4 Inches X 7 Inches (1306039) +$106.81

QTY: 8-32 X 2 Inches Slotted Round Head Screw (1201243) +$10.95

QTY: 48 Top ~Old Part #1306053~ (1306053A) +$352.12

QTY: 50-Flue Collar 6 Inches ~Old Part #7000969~ (7000969A) +$169.43

QTY: Flue Collar 6 Inches Red ~Old Part #2320969~ (SRV2320969) +$528.00

QTY: Primary Air Actuator Arm (1606060) +$32.76

QTY: 52-Leg 4_BEIN ~Old Part #1306054~ (1306054A) +$124.68

QTY: 80-Damper Handle Gold with Set Screw (5004267) +$89.91

QTY: 55-Refractory Assembly (1602515) +$260.50

QTY: 64-Ash Pan (7000G69) +$142.02

QTY: 70-Probe Thermometer ~Old Part #7000948~ (7000948A) +$126.02

QTY: 71-Gasket Fiberglass [15ft per package] ~Old Part #1203589~ (1-00-1203589) +$52.93

QTY: 73-Andiron ~Old Part #1306052~ (1306052A) +$92.67

QTY: 76-Air Manifold (1306049) +$81.70

QTY: 77-Inner Top Web ~Old Part #7001110~ (7001110A) +$134.02

QTY: 77A Inner Top Web Interam Gasket [2 per unit, each sold separately] (1203540) +$11.03

QTY: 1/4 -20 X 1 Inch Hex Head Leveler Bolt (1201745) +$12.95

QTY: Brass Handle (000A902) *No Longer Available* +$*0.00*

QTY: Inner Side Plate (1306051) +$112.28

QTY: 4MM X 14MM Phillips TRS Head Sheet Metal Screw [StovePipe to Flue Collar] (1202089) *No Longer Available* +$*0.00*

QTY: 8MM X 1 1/4 PHIL TRUS Head WD Screw [WALL Bracket] (1201301) *No Longer Available* +$*0.00*

QTY: 1/4_20 X 1/2 Hex Head Cap Screw [Heat Shield By-Pass Connector Clip Sequoia Glass Frame] (1201338) +$11.95

QTY: BC-20 Hex Nut [Heat Shield] (1203210) +$10.46

QTY: Phillips Flat Head Screw (1200881) +$12.26

QTY: 1/4_20 X 1-1/4 Hex Head Cap SCottage Red [Bottom Back Leg Bolt] (1201378) +$12.26

QTY: 1/4 X 7/8 Flat Washer [Bottom Back Front Top Leg Bolt] (1202470) +$11.59

QTY: 1/4_20 X 3/4 Hex Head Cap Screw [Side Part Rear Part By-Pass Gate Side Support Grate Back Side Half Wall BOOT Plate Sequoia Inner Back & Flue Collar] (1201374) +$10.46

QTY: 1/4 STD Flat Washer [Side & Rear Part Back Baffle Top Front Door BOOT Plate Sequoia Inner Back Sides Front Grate Back Hinges] (1202474) +$11.95

QTY: 1/4_20 X 5/8 Phillips Flat Head Machine Screw [Back Cover Panel] (1200865) +$16.78

QTY: 1/4_20 X 5/8 Hex Head Cap Screw [Back Inlet Plate Sequoia Hinges & Hearth (1201372) +$11.95

QTY: 1/4_20 X 1-1/2 CRS Stud [Back Front Top] (1204214) +$26.37

QTY: 1/2-20 Hex Nut [Back Front Top Sides to Bottom A Plus Ashdoor Frame] (1203210) +$10.46

QTY: Hinge Pin (1201836) +$11.03

QTY: Sequoia Ashdoor Hinge Pin (1201837) +$19.46

QTY: 1/4_20 X 1 Hex Head Cap Screw [Baffle A Plus Ash Bin] ~Old Part #1201326~ (1201370) +$12.45

QTY: 1/4_20 X 1/2 Hex Head Cap Screw [Door Panel Torsion Bar Clip] (1201338) +$11.95

QTY: 3/8-16 Hex Jam Nut [Door Shaft] ~Old Part #1203157~ (1203290) +$10.46

QTY: 1/4 X 1-1/4 Fender Washer [Rocker Grate] (1202527) +$10.46

QTY: 1/4_20 X 1-1/2 Phillips Flat Head Screw [Rocker Grate] (1200815) +$11.18

QTY: Wing Nut 1/4_20 [Rocker Grate] (1203110) +$12.47

QTY: 10-24 X 1/2 Hex Head Cap Screw [Rocker Grate] (1201322) +$14.66

QTY: 3/8-16 X 1-1/2 Hex Head Cap Screw [By-Pass Grate Connector] (1201456) +$11.95

QTY: 3/8-16 Hex Top Lock Jam Nut [By-Pass Grate Connector] (1203290) +$10.46

QTY: 1/4_20 X 7/8_94 10MM Hex Head Cap Screw [Top Side for Shroud] (1201375) *No Longer Available* +$*0.00*

QTY: 7/16 X 5/8 Lock Washer [Brass Dial] (1202463) +$Call to Order

QTY: 3/8-16 Narrow Hex Nut [Brass Dial] (1203161) +$10.46

QTY: 1/4_20 X 1 3/4 Phillips Flat Head [Sides to Bottom A Plus Ashdoor Frame] (1200830) +$14.95

QTY: 1/4 X 3/4 Washer [GrateBack] ~Old Part #1202469~ (1202470) +$11.59

QTY: 1/4_20 X 2 Pin Hex Head CS [Inner Top Channel Sequoia Baffle] (1201392) +$13.91

QTY: 1/4_20 X 1 1/4 Stud [Sequoia Back] (1204212) +$12.15

QTY: 1/4_20 X 2 Phillips Flat HD MS [Sequoia Air Distributor ] [each sold separately] ~Old Part #s 120848, SRV1200848~ (1200848) +$10.86

QTY: 1/4_20 X 1 1/4 Phillips Flat Head Screw [Sequoia Shaker Grate Cover Inlet Plate] (1200811) +$11.95

QTY: 1/4_20 1 Phillips Flat Head Screw [Sequoia Top] (1200809) +$11.95

QTY: 1/4 Flat Washer [Sequoia Side Hinge] {each sold separately] (1202473) +$11.59

QTY: 5/16-18 X 5/16 Socket Set Screw [Sequoia Door Catch] (1200563) +$14.95

QTY: 1/4 X .5 OD Flat Washer [Sequoia Hearth] (1202475) +$12.26

QTY: 1/4_20 X 1 Hex Head Cap Screw [Sequoia Leg Bolt] (1201376) +$11.95
