Defiant Catalytic Wood Stove (1975-CAT-C) #1975-CAT-C

Defiant Catalytic Wood Stove (1975-CAT-C)

Item#: 1975-CAT-C

Price: $0.00


Order Now

Beginning Manufacturing Date is October 2019

Includes Models: 1975-CAT-C Classic Black, 1976-CAT-C Biscuit, 1977-CAT-C Majolica Brown, 1979-CAT-C Bordeaux, 1980-CAT-C Twilight, 1975T-CAT-C Classic Black with Transition Doors

MAIN ASSEMBLY

Item Description (Part Number)

QTY: 1 Brick Support Bracket [2 per unit, each sold separately] (30005279) +$113.64

QTY: 2 Griddle Gasket [10 ft per package] (1-00-1203668) +$76.66

QTY: 3 Back (30005245A) +$Call to Order

QTY: 4 Right End Refractory (30005206) +$136.89

QTY: 5 Left End Refractory (30005207) +$136.89

QTY: 6 Refractory Support (30005233) +$79.46

QTY: 7 Cast Base Gasket (SRV8344-000) +$103.34

QTY: 8 Back Insulation Board (30005269) +$116.38

QTY: 9 Outer Back (30005249) +$372.19

QTY: 10 Left Griddle Quadrant (30002399A) +$68.80

QTY: 11 Right Griddle Quadrant (30002401A) +$59.46

QTY: 12 Griddle (30005257A) +$338.20

QTY: 13 Complete Griddle Handle (30002775) +$105.44

QTY: 13A Wood Griddle Handle (1600661) +$12.47

QTY: 13B Griddle Handle (30002715) +$48.50

QTY: 13C Hex Nut [each sold separately] (1203210) +$10.46

QTY: 14 Griddle Handle Bushing [each sold separately] (1201900) +$12.26

QTY: 15 Griddle Handle Bolt [each sold separately] (1201308) +$10.95

QTY: 16 Damper Gasket [15 ft per package] [need Gasket Glue] (1-00-1203588) +$59.46

QTY: 16A Gasket Glue (77) +$9.46

QTY: 17 Damper Ramp (1300643) +$29.25

QTY: 18 Damper Housing (30002821A) +$221.80

QTY: 18A Damper Housing Gasket[15 ft per package] (1-00-30001910) +$91.33

QTY: 19 Damper (30002816) +$120.48

QTY: 20 Damper Tab [4 per unit, each sold separately] [Screw sold separately] (1601488) +$11.18

QTY: 20A Hex Screw for Damper Tab (1201338) +$11.95

QTY: 21 Damper Rod (1600065) +$151.93

QTY: 23 Back Refractory Gasket [2 per unit, each sold separately] (1-00-30005270) +$68.80

QTY: 24 Rheostat Bracket (30002863) +$78.09

QTY: 25 Engine Refractory (30005202) +$418.56

QTY: 26 Damper Handle Screw (1201310) +$11.95

QTY: 27 Damper Handle (1600664) +$12.47

QTY: 27A Bolt [for Damper Handle] (1201294) +$14.95

QTY: 28 Damper Handle with Screw (30002720A) +$103.34

QTY: 29 Left Side [Classic Black] (30002832A) +$266.28

QTY: 29A Left Side [Biscuit] (SRV30002872) +$553.00

QTY: 29B Left Side [Bordeaux] (SRV30006697) +$737.00

QTY: 29C Left Side [Majolica Brown] (SRV30004834) +$516.00

QTY: 29D Left Side [Twilight] (SRV30007126) +$479.00

QTY: 30 Left Air Manifold (30002818) +$106.81

QTY: 31 Right Air Manifold (30005243) +$115.01

QTY: 32 Right Side [Classic Black] (30002831A) +$266.28

QTY: 32A Right Side [Biscuit] (SRV30002871) +$553.00

QTY: 32B Right Side [Bordeaux] (SRV30006698) +$750.00

QTY: 32C Right Side [Majolica Brown] (SRV30004835) +$504.00

QTY: 32D Right Side [Twilight] (SRV30007127) +$504.00

QTY: 33 Thermostat Handle Base (30002716) +$51.23

QTY: 33A Thermostat Knob (1600660) +$12.47

QTY: 34 Washer Damper Rod [each sold separately] (30007257) +$Call to Order

QTY: 35 Stainless Steel Fireback Plate and Gasket ~Old Part #s 30005217, SRV8000-008~ (SRV8787-021) +$191.35

QTY: 36 Inner Bottom (30005241) +$258.04

QTY: 37 Top Ashdoor Hinge (1-00-30002836) *No Longer Available* +$*0.00*

QTY: 37A Ashdoor with Hinge and Support (SRV30002810) +$323.12

QTY: 37B Bolt [12 per package] (27887/12) +$42.26

QTY: 37C Nut [each sold separately] (SRV8787-007) +$Call to Order

QTY: 38 Door Handle Bracket (30002844) +$117.74

QTY: 39 Bottom (30005240A) +$565.00

QTY: 40 Ashlip [Classic Black] (30002811A) +$191.35

QTY: 40A Ashlip [Biscuit] (SRV30002870) +$295.28

QTY: 40B Ashlip [Bordeaux] (SRV30006696) +$352.12

QTY: 40C Ashlip [Majolica Brown] (SRV30004833) +$295.28

QTY: 40D Ashlip [Twilight] (SRV30007125) +$553.00

QTY: 41 Fireback Gasket ~Old Part # 30005209~ (CFPAP1/8-48-65-2) +$33.42

QTY: 42 Fireback Refractory ~Old Part # 30005203~ (SRV8787-075) +$540.00

QTY: 43 Fireback Refractory Retainer [2 per unit, each sold separately] (30005248) +$44.39

QTY: 44 Inner Cover Refractory (30005205) +$115.01

QTY: 45 Andiron [2 per unit, each sold separately] (30002827A) +$90.00

QTY: 45A Screw [for Andiron] [each sold separately] (1201337) +$10.46

QTY: 45B Washer [for Andiron] [each sold separately] (1202470) +$11.59

QTY: 46 Refractory Access Cover (30007252) +$245.52

QTY: 47 Leg Leveler [4 per unit, each sold separately] (1201745) +$12.95

QTY: 48 Ashdoor Handle Shaft (30005301) +$110.91

QTY: 49 Pawl Assembly [2 per unit, each sold separately] (30005157) +$53.96

QTY: 49A Nut Jam [for Pawl Assembly] [each sold separately] (1203290) +$10.46

QTY: 49A Spring Washer [each sold separately] (63D0069) +$11.18

QTY: 50 Ashdoor [Serial pre 0081391652] (30002810A) +$236.42

QTY: 50 Ashdoor with Hinge and Support [Serial Post 0081391652] (SRV30002810) +$323.12

QTY: 50A Ashdoor Gasket [15 ft per package] (1-00-1203589) +$52.93

QTY: 51 Ashdoor Wood Handle (1600663) +$13.91

QTY: 52 Hinge Hardware (1-00-2826) +$43.59

QTY: 53 Ceramic Fiber Gasket [2 per unit, each sold separately] (SRV30007513) +$104.67

QTY: 54 Ashdoor Bottom Hinge Support ~Old Part #s 1300642, 1-00-1300642~ (1300642A) +$94.00

QTY: 54A Bolt [12 per package] (27887/12) +$42.26

QTY: 54B Nut [each sold separately] (SRV8787-007) +$Call to Order

QTY: 55 Ashpan Bracket (30001908A) +$104.67

QTY: 56 Rear Side Bracket [4 per unit, each sold separately] (30002845) +$30.68

QTY: 57 Thermostat Handle (1600660) +$12.47

QTY: 58 Front Airwash Manifold (30005244) +$180.60

QTY: 59 Front [Classic Black] (30002830A) +$479.00

QTY: 59A Front [Biscuit] (SRV30002873) +$721.00

QTY: 59B Front [Bordeaux] (SRV30006699) +$1020.00

QTY: 59C Front [Majolica Brown] (SRV30004836) +$752.00

QTY: 59D Front [Twilight] (SRV30007128) +$811.00

QTY: 60 Flue Collar Gasket [15 ft per package] (1-00-30002422) +$77.99

QTY: 61A Left Door Shell Enamel Parts [Classic Black] (30002813A) +$199.88

QTY: 61A Left Door Shell Enamel Parts [Biscuit] (SRV30002876) +$403.16

QTY: 61A Left Door Shell Enamel Parts [Bordeaux] (SRV30006703) +$577.00

QTY: 61A Left Door Shell Enamel Parts [Majolica Brown] (SRV30004842) +$430.00

QTY: 61A Left Door Shell Enamel Parts [Twilight] (SRV30007132) +$395.04

QTY: 61A Left Door Sub Assembly [Classic Black] [no Glass, Gasket] (30002854) +$448.28

QTY: 61A Left Door Sub Assembly [Biscuit] [no Glass, Gasket] (30002879) +$730.20

QTY: 61A Left Door Sub Assembly [Bordeaux] [no Glass, Gasket] (30006773) +$502.65

QTY: 61A Left Door Sub Assembly [Majolica Brown] [no Glass, Gasket] (30004840) +$566.20

QTY: 61A Left Door Sub Assembly [Twilight] [no Glass, Gasket] (30007133) +$476.82

QTY: 61B Left Door Transition Door Enamel [Classic Black] (30007091A) +$298.76

QTY: 61B Left Door Transition Door Enamel [Biscuit] (SRV30007093) +$454.00

QTY: 61B Left Door Transition Door Enamel [Bordeaux] (SRV30007097) +$577.00

QTY: 61B Left Door Transition Door Enamel [Majolica Brown] (SRV30007095) +$430.00

QTY: 61B Left Door Transition Door Enamel [Twilight] (SRV30007109) +$451.88

QTY: 61B Left Door Sub Assembly Transition Door Enamel [Classic Black] (30007175) +$451.40

QTY: 61B Left Door Sub Assembly Transition Door Enamel [Biscuit] (30007177) +$566.20

QTY: 61B Left Door Sub Assembly Transition Door Enamel [Bordeaux] (30007179) +$528.28

QTY: 61B Left Door Sub Assembly Transition Door Enamel [Majolica Brown] (30007181) +$566.20

QTY: 61B Left Door Sub Assembly Transition Door Enamel [Twilight] (30007183) +$515.98

QTY: 62 Door Hinge Strip [2 per unit, each sold separately] (13000645A) +$Call to Order

QTY: 63 Top [Classic Black] (30002834A) +$482.04

QTY: 63A Top [Biscuit] (SRV30002874) +$971.00

QTY: 63B Top [Bordeaux] (SRV30006700) +$1230.00

QTY: 63C Top [Majolica Brown] (SRV30004837) +$983.00

QTY: 63D Top [Twilight] (SRV30007129) +$670.00

QTY: 64 Glass Clip [3 per unit, each sold separately] (30001715) +$91.76

QTY: 65 Glass Clip [Right Door Only] (30001716) +$91.76

QTY: 65A Glass Clip Screw [each sold separately] (1200998) +$10.46

QTY: 66 Front Door Handle and Shaft (30002717) +$94.50

QTY: 67A Right Door Shell Enamel Parts [Classic Black] (30002812A) +$280.20

QTY: 67A Right Door Shell Enamel Parts [Biscuit] (SRV30002875) +$437.96

QTY: 67A Right Door Shell Enamel Parts [Bordeaux] (SRV30006702) +$577.00

QTY: 67A Right Door Shell Enamel Parts [Majolica Brown] (SRV30004841) +$455.36

QTY: 67A Right Door Shell Enamel Parts [Twilight] (SRV30007131) +$451.88

QTY: 67A Right Door Sub Assembly Shell Enamel [Classic Black] [no Glass, Gasket] (30002853) +$359.11

QTY: 67A Right Door Sub Assembly Shell Enamel [Biscuit] [no Glass, Gasket] (30002878) +$806.05

QTY: 67A Right Door Sub Assembly Shell Enamel [Bordeaux] [no Glass, Gasket] (30006772) +$521.10

QTY: 67A Right Door Sub Assembly Shell Enamel [Majolica Brown] [no Glass, Gasket] (30004839) +$566.20

QTY: 67A Right Door Sub Assembly Shell Enamel [Twilight] [no Glass, Gasket] (30007134) +$374.57

QTY: 67B Right Door Transition Enamel [Classic Black] (30007090A) +$284.84

QTY: 67B Right Door Transition Enamel [Biscuit] (SRV30007092) +$454.00

QTY: 67B Right Door Transition Enamel [Bordeaux] (SRV30007096) +$590.00

QTY: 67B Right Door Transition Enamel [Majolica Brown] (SRV30007094) +$430.00

QTY: 67B Right Door Transition Enamel [Twilight] (SRV30007108) +$451.88

QTY: 67B Right Door Sub Assembly Transition Enamel [Classic Black] (30007176) +$509.83

QTY: 67B Right Door Sub Assembly Transition Enamel [Biscuit] (30007178) +$616.43

QTY: 67B Right Door Sub Assembly Transition Enamel [Bordeaux] (30007180) +$830.65

QTY: 67B Right Door Sub Assembly Transition Enamel [Majolica Brown] (30007182) +$616.43

QTY: 67B Right Door Sub Assembly Transition Enamel [Twilight] (30007184) +$566.20

QTY: 68 Door Gasket [15 ft per package] (1-00-7000910) +$63.46

QTY: 69 Glass Gasket [10 ft per package] (1-00-1186258229) +$34.32

QTY: 70 Left Door Glass (30005247) +$214.31

QTY: 71 Right Door Glass (30005247) +$214.31

QTY: 72 Lower Door Hinge Pin [2 per unit, each sold separately] (30002727) +$11.03

QTY: 73 Spacer [each sold separately] (1201779) +$12.95

QTY: 74 Upper Door Hinge Pin [2 per unit, each sold separately] (30002727) +$11.03

QTY: 75 Black Wood Handle [includes: Black Handle, Screw & Nickel Nub] (30004175K) +$83.33

QTY: 75A Handle Base Stub (30002714) +$34.99

QTY: 75B White Ceramic Handle with Screw and Insert (0004342) *No Longer Available* [can sub black handle 30004175K] +$*0.00*

QTY: 75C Stainless Steel Socket for Handle (1200334) +$10.99

QTY: 76 Black Maple Damper Handle [Wood Part Only] [Earlier Models had a White Porcelain Handle. this Handle has been replace with a Black Handle] (1600664) +$12.47

QTY: 77 Handle Bolt (1201310) +$11.95

QTY: 78 Thermostat Handle Bolt (1201243) +$10.95

QTY: 79 Ash Pan (30001690) +$216.81

QTY: 80 Flue Collar [Classic Black] (30001576A) +$236.42

QTY: 80A Flue Collar [Biscuit] (SRV30002947) +$465.80

QTY: 80B Flue Collar [Bordeaux] (SRV30006701) +$441.00

QTY: 80C Flue Collar [Majolica Brown] (SRV30004815) +$465.80

QTY: 80D Flue Collar [Twilight] (SRV30007130) +$408.96

QTY: 81 Leg [Classic Black] [4 per unit, each sold separately] (30002835A) +$104.67

QTY: 81A Leg [Biscuit] [4 per unit, each sold separately] (SRV30002877) +$193.79

QTY: 81B Leg [Bordeaux] [4 per unit, each sold separately] (30006695A) +$218.15

QTY: 81C Leg [Majolica Brown] [4 per unit, each sold separately] (30004843A) +$187.70

QTY: 81D Leg [Twilight] [4 per unit, each sold separately] (SRV30007124) +$210.84

QTY: 82 Jam Nut [each sold separately] (1203290) +$10.46

QTY: 83 Bottom Heat Shield (30005037) +$166.87

QTY: 83A Bottom Heat Shield [Right Wing] (30005038) +$146.90

QTY: 83B Bottom Heat Shield [Left Wing] (30005039) +$145.09

QTY: 84 Grate Bottom (30005234A) +$223.02

QTY: 85 Thermostat (5005470) +$105.44

QTY: 85A Washer for Thermostat (1202471) +$12.26

QTY: 86 Thermostat Cable (5005471) +$43.03

QTY: 87 Thermostat Friction Spring (1201846) +$12.95

QTY: 88 Primary Air Valve (30005275) +$170.62

QTY: 89 Heat Plate Vertical Flue (30005265) +$198.08

QTY: 90 Ceramic Catalyst (30006623) +$401.91

QTY: 91 Thermostat Handle (30007067) +$109.54

QTY: 92 Primary Air Cover (30007069) +$119.11

QTY: 93 Primary Air Base (30007071) +$121.85

QTY: 94 Temperature Probe (30007274) +$141.97

QTY: 95 Temperature Probe Bracket (30007278) +$36.43

QTY: 96 Slotted Refractory Gasket and Fireback Plate ~Old Part # SRV8344-001~ (SRV8787-021) +$191.35

QTY: 97 Finish Bag (SRV8000-007) +$176.74

QTY: 98 Owners Manual [hard copy] [8390-975] (OMHC-VC) +$9.99

QTY: 99 Owners Manual [electronic copy] [8390-975] (OMEL-VC) +$0.00

QTY: 100 Vermont Casting Leather Stove Glove (0000112) +$61.95

QTY: 101 Stove Surface Thermometer (0000574) +$105.87

QTY: 102 Cast Iron Steamer Ebony Black Enamel (0000784) *No Longer Available* +$*0.00*

STOVE PIPE

Item Description (Part Number)

QTY: 110 8 Inch Oval to 8 Inch Round Low Profile Stove Adapter Black (0001836) +$179.17

QTY: 111 8 Inch Oval to 8 Inch Round Standard Adapter Black (0001855) +$93.45

QTY: 112 8 Inch Oval to 8 Inch Round Elbow Black (0001846) +$191.35

QTY: 113 8 Inch Oval to 6 Inch Round Adapter Black (0001860) +$138.02

QTY: 114 8 Inch Oval to 8 Inch Round Offset Stove Adapter Black (0001841) +$179.17

WARMING SHELF KITS

[Includes: 1 Shelf, 1 Left Bracket, 1 Right Bracket, 1 Dragon Bracket, 2 Mittenracks and Hardware]

Item Description (Part Number)

QTY: 120 Warming Shelf Kit [Classic Black] (0000210) +$250.95

QTY: 121 Warming Shelf Kit [Biscuit] (0000211) *No Longer Available* [can sub indivdual pieces] +$*0.00*

QTY: 122 Warming Shelf Kit [Brown Majolica] (0000217) +$408.45

QTY: 123 Warming Shelf Kit [Bordeaux] (0000218) +$502.95

QTY: 124 Warming Shelf Kit [Twilight] (0000219) +$366.45
QTY:

Continue Shopping


SmartCart Ecommerce System SmartCart® Ecommerce


© 2014 Cozy Cabin Vermont Castings Parts Store
518-623-4349

Website Design by Nolee-O Web Design
