  Main : Coal Burning : Coal Stove Parts

Coal Fireplace Insert Item#: 1271-1272 Price: $0.00 Order Now EXTERIOR PARTS [NOTE: PORCELAIN ENAMELED PARTS ARE NO LONGER AVAILABLE FOR THE FIREPLACE INSERT] Item Description (Part Number) QTY: 1- 3_94 CAST ROLLER (1203322) +$Call to Order QTY: 2- 3/8-16 X 2 1/2_94 HEX HEAD CAP SCREW (1201463) +$Call to Order QTY: 4- BODY (1604402) +$Call to Order QTY: 5- 1/4 FENDER WASHER (1202527) +$12.26 QTY: 6- 1/4 -20 HEX NUT (1203210) +$11.18 QTY: 7- ENCLOSURE TOP (1604415) +$Call to Order QTY: 8- 1/4 FLAT WASHER (1202474) +$11.18 QTY: 9- FRONT (1307093) +$Call to Order QTY: 10- GASKET [15FT] ~Old Part #1203588~ (1-00-1203588) +$45.67 QTY: 11- 1/4 -20 X 1 1/2_94 PHILLIPS FLAT HEAD (1200811) +$11.18 QTY: 12- 1/4 -20 KEPS NUT (1203305) +$11.18 QTY: 13- WIREWAY (1204922) +$Call to Order QTY: 14- COMPLETE WIRE HARNESS (5002692) +$Call to Order QTY: 17- DAMPER PULL (1600880) +$18.23 QTY: 18- WIREWAY ELBOW (1204934) +$Call to Order QTY: 19- 10-24 X 1/4_94 PHILLIPS PAN HEAD SCREW (1200980) +$11.18 QTY: 20- LEFT BLOWER ~Old Part # 1604107 (FK12) +$405.80 QTY: 21- LEFT BLOWER ENCLOSURE (1604210) +$Call to Order QTY: 22- #8 X 1/2_94 PHILLIPS PAN HEAD SMS (1200989) +$11.18 QTY: 23- 10-24 X 3/4_94 PHILLIPS TRS HEAD SCREW (1201007) +$14.31 QTY: 24- 10-24 HEX NUT (1203251) +$11.18 QTY: 25- BLOWER BRACKET INSULATION (1203514) +$20.51 QTY: 26- LEAD ASSEMBLY BLACK (5002569) +$Call to Order QTY: 27- LEAD ASSEMBLY WHITE (5002574) +$Call to Order QTY: 28- RIGHT BLOWER (1604114) *No Longer Available* +$ *0.00* QTY: 28A- BLOWER BUSHING ASSEMBLY (5002628) +$47.25 QTY: 29- RIGHT BLOWER ENCLOSURE (1604217) +$Call to Order QTY: 30- THERMOSTAT ROD ASSEMBLY (5002645) +$Call to Order QTY: 30A- THERMOSTAT KNOB (1204791) +$Call to Order QTY: 31- THERMOSTAT CLIP (1601408) +$11.38 QTY: 32- THERMOSTAT SPRING (1201850) +$Call to Order QTY: 33- THERMOSTAT BALL CHAIN (1201960) +$12.84 QTY: 33A- EYELET THERMOSTAT (1201864) +$11.38 QTY: 34&35- LEFT AIR SHUTTER ASSEMBLY (5002626) +$Call to Order QTY: 36- THERMOSTAT CABLE [SOLD PER FOOT-2 FT NEEDED] (1204867) +$11.18 QTY: 37- PIN (1601583) +$Call to Order QTY: 38- PUSH ON RETAINERS (1203053) +$Call to Order QTY: 39&40- RIGHT AIR SHUTTER ASSEMBLY (5002622) +$Call to Order QTY: 41- LEFT DOOR (1307175) +$Call to Order QTY: 41A- BRASS LEFT DOOR (1307176) +$Call to Order QTY: 42- 5/16_94 ARMASEAL DOOR SEAL [10 FT] ~Old Part #1203668~ (1-00-1203668) +$62.29 QTY: 43- GLASS [9 3/4_94 X 14_94] (1401160) +$184.57 QTY: 44- 3/16_94 4ND BLACK FIBERGLASS GASKET [10FT] ~Old Part #s 1203556, 1203556A, 1-00-1203556~ (1-00-1186258229) +$25.69 QTY: 45- GLASS RETAINER (1604313) +$Call to Order QTY: 46- RIGHT DOOR (1307177) +$Call to Order QTY: 46A- BRASS RIGHT DOOR (1307178) +$Call to Order QTY: 47- HINGE DOOR TOP RIGHT & BOTTOM LEFT (1604272) +$Call to Order QTY: 48- 10-24 X 3/8 PH FLAT HEAD (1200939) +$Call to Order QTY: 49- #10 EXTERNAL TOOTH LOCK WASHER (1202468) +$11.18 QTY: 50- DOOR PIN UPPER 3/16 X 1_94 (1600401) +$Call to Order QTY: 51- HINGE DOOR TOP LEFT & BOTTOM RIGHT (1604276) +$Call to Order QTY: 52- DOOR PIN LOWER (1600415) +$Call to Order QTY: 53- #10 FLAT WASHER (1202423) +$11.38 QTY: 54- HANDLE STUB GOLD [FRONT AND SIDE NUB WITH SHAFT] (5004273) +$73.47 QTY: 55- WIRE FORM ONLY (1600694) +$28.62 QTY: 56- WOOD HANDLE ONLY (1600682) +$18.71 QTY: 57- INSERTER LIFTER HANDLE GOLD NUB ONLY (1600651) +$34.49 QTY: 55- WIREFORM FALLAWAY HANDLE COMPLETE GOLD (0004349) +$95.68 QTY: 58- PAWL ASSEMBLY 5004025 (30005157) +$54.05 QTY: 58A- ALLEN WRENCH FOR PAWL ASSEMBLY (1205116) +$12.84 QTY: 59- 1/4 -20 X 1/4_94 SOCKET HEAD SET SCREW (1200417) +$11.18 QTY: 60- 3/8-16 JAM NUT (1203290) +$11.18 QTY: 61- 1/4 -20 X 1_94 SOCKET HEAD SET SCREW (1200436) +$11.18 QTY: 62- UPPER FRONT (1307157) +$Call to Order QTY: 63- 1/4 -20 X 5/8_94 PHILLIPS ROUND HEAD SCREW (1200896) +$11.18 QTY: 64- 1/4 EXTERNAL TOOTH LOCK WASHER (1202461) +$11.18 QTY: 65- LEFT COLUMN (1307133) +$Call to Order QTY: 66- BLOWER INLET SCREEN 4114 (1604163) +$Call to Order QTY: 67- AIR INLET SCREEN (1604182) +$Call to Order QTY: 68- POWER RECEPTACLE (1204970) +$Call to Order QTY: 69- LEAD ASSEMBLY GREEN (5002581) +$Call to Order QTY: 70- POWER RECEPTACLE COVER (1204976) +$Call to Order QTY: 71- PRESS CLIP (1203038) +$Call to Order QTY: 72- JUNCTION BOX COVER PLATE (1604031) +$Call to Order QTY: 73- CENTER MANTEL (1307204) +$Call to Order QTY: 74- LEFT MANTEL (1307243) +$Call to Order QTY: 75- RIGHT MANTEL (1307256) +$Call to Order QTY: 76- 1/4_20 X 3_94 TIE THREADED ROD (1601653) +$Call to Order QTY: 77- RIGHT COLUMN (1307146) +$Call to Order QTY: 78- ELECTRICAL CORD (1204816) *No Longer Available* +$87.81 QTY: 79- ASH PAN (1400975) +$Call to Order QTY: 80- ASH DOOR COVER (1307035) +$Call to Order QTY: 82- ASH DOOR HANDLE WOOD ONLY [SHAFT NOT AVAILABLE] (1600663) +$12.84 QTY: 83- RHEOSTAT FOR FAN (0004820) +$Call to Order QTY: 84- TOP INSULATION (1203503) +$Call to Order QTY: 85- 10-24 X 1/4_94 PHILLIPS PAN HEAD (1200980) +$11.18 QTY: 86- LEFT TOP BRASS TRIM (1402490) +$Call to Order QTY: 87- LEFT BOTTOM BRASS TRIM (1402493) +$Call to Order QTY: 88- 8-32 X 3/4_94 PHILLIPS ROUND HEAD SCREW (1201058) +$Call to Order QTY: 89- 8-32 X 1/2_94 PHILLIPS ROUND HEAD SCREW (1201050) +$Call to Order QTY: 90- RIGHT TOP BRASS TRIM (1402496) +$Call to Order QTY: 91- RIGHT BOTTOM BRASS TRIM (1402499) +$Call to Order QTY: 92- CONTROL KNOB (1204791) +$Call to Order QTY: 93- WIRE SLEEVES (1204877) +$Call to Order QTY: 94- LEFT BLOWER HEAT SHIELD (1604101) +$Call to Order QTY: 95- RIGHT BLOWER HEAT SHIELD (1604103) +$Call to Order INTERIOR FIREBOX PARTS Item Description (Part Number) QTY: 1- CAM BAR (1307335) +$Call to Order QTY: 2- FACE PLATE (1307340) +$Call to Order QTY: 3- HI-GRATE BAR (1307347) +$26.70 QTY: 4- LEFT SIDE (1307318) +$Call to Order QTY: 5- LOW-GRATE BAR (1307354) +$122.01 QTY: 6- REAR SUPPORT (1307311) +$Call to Order QTY: 7- RIGHT SIDE (1307323) +$Call to Order QTY: 8- FIREBRICK SPLIT [9 X 4 1/2_94 FIREBRICK SLIM] (1601103) +$12.84 QTY: 14- FRONT GRATE BAR [4 USED] (1307048) +$248.54 QTY: 10- BAFFLE (1307362) +$Call to Order QTY: 15- SHAKER ROD ASSEMBLY (1600749) +$Call to Order GASKETS Item Description (Part Number) QTY: 96- LEFT DOOR SEAL GASKET [10FT] ~Old Part #1203668~ (1-00-1203668) +$62.29 QTY: 97- RIGHT DOOR SEAL GASKET [10FT] ~Old Part #1203668~ (1-00-1203668) +$62.29 QTY: 98- ASH DOOR GASKET [10FT] ~Old Part #1203668~ (1-00-1203668) +$62.29 QTY: 99- AIR INLET SEAL GASKET [10FT] ~Old Part #s 1203560-1, 1-00-1203560~ (834-1460) +$55.45 QTY: 100- FRONT FRAME GASKET [15FT] ~Old Part #1203588~ (1-00-1203588) +$45.67 QTY: 101- LEFT OR RIGHT GLASS PANEL GASKET [10 FT] ~Old Part #s 1203556, 1203556A, 1-00-1203556~ (1-00-1186258229) +$25.69 QTY: 102- GLASS GASKET KIT (0003427) +$125.03

QTY:
