Manufactured Between June 1988 - June 1993
MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1 Magazine Top (1301756) *No Longer Available* +$*0.00*
QTY: 2 Magazine Back (1301754) *No Longer Available* +$*0.00*
QTY: 3 Magazine Front (1301752) *No Longer Available* +$*0.00*
QTY: 4 10-24 X 1/2 Ph Truss Screw [50 per package] (3-30-1115-50) +$44.93
QTY: 4A Magazine Nut [10-24 Hex Nut] (1203251) +$14.95
QTY: 5 Half Throat [1] (1301750) +$208.17
QTY: 6 Magazine Clip (1600947) *No Longer Available* +$*0.00*
QTY: 7 Magazine Clip Screw [each sold separately] (1200998) +$10.46
QTY: 8 Shaker Handle (1600903) +$Call to Order
QTY: 9 Shaker Support (1301935) *No Longer Available* +$*0.00*
QTY: 10 Long Leg Bolt [10 per package] (1201456-10) +$31.52
QTY: 11 Ash Pan (5005772) *No Longer Available* +$*0.00*
QTY: 12 Slicer/Poker (5005708) +$61.93
QTY: 13 Retainer Shelf (1301763) *No Longer Available* +$*0.00*
QTY: 14 Upper Exhaust Manifold (1301765) *No Longer Available* +$*0.00*
QTY: 15 Lower Exhaust Manifold (1301767) *No Longer Available* +$*0.00*
QTY: 16 Shaker Rod (1600913) *No Longer Available* +$*0.00*
QTY: 17 Coal Arm Cam (1301939) *No Longer Available* +$*0.00*
QTY: 18 Linkage [Drilled for Cotter Pins] (1301908) *No Longer Available* +$*0.00*
QTY: 19 Front Grate (1301720) +$106.73
QTY: 20 Back Grate (1301730) +$Call to Order
QTY: 21 Left Grate (1301700) +$Call to Order
QTY: 22 Right Grate (1301710) +$Call to Order
QTY: 23 Bottom Grate w/ Welded Arm (5002139) +$Call to Order
QTY: 24 Magazine Door (1301758) *No Longer Available* +$*0.00*
QTY: 25 Magazine Door Hinge Pin [each sold separately] (1600535) +$10.86
QTY: 26 Chain Screw 10-24 X 1/4 PH Pan Head [10 per package] (1200980-10) +$24.52
QTY: 27 Magazine Chain [8 Links] (1206048) +$Call to Order
QTY: 30 Cotter Pins (1203028) +$Call to Order
QTY: 31 Coal Kit Hardware (5006378) *No Longer Available* +$*0.00*
QTY: 32 Coal Stove Plug [Threaded] (1200055) *No Longer Available* +$*0.00*
QTY: 33 Tube of Furnace Cement (0004470) +$Call to Order
QTY: 34 2 Rear Heat Shield Spacers [set of 2] (5007110) +$201.10
QTY: 35 Bottom Heat Shield Spacers [4] (0005802) +$126.02
QTY: 36 Rear Heat Shield (1402108) +$209.05
QTY: 37 Bottom Heat Shield (1402229) +$158.34
QTY: 38 Outside Air Kit (0003256) *No Longer Available* +$*0.00*
QTY: 39 Mobile Home Kit (0003215) *No Longer Available* +$*0.00*
QTY: 40 Long Leg [1 only] (1301503) +$109.73
QTY: 41 Short Leg [1 only] ~Old Part # 1300663~ (1300663A) +$126.02
QTY: 42 Warming Shelf ~Old Part # 1302208~ (1302208A) +$150.03
QTY: 43 Screen (0000140) +$156.28
QTY: 44 Ash Fettle Assembled (5002808) *No Longer Available* +$*0.00*
QTY: 46 Ash Fettle Back (1301779) *No Longer Available* +$*0.00*
QTY: 47 Ash Fettle Front (1301773) *No Longer Available* +$*0.00*
QTY: 49 Left Glass Retainer (1601401) *No Longer Available* +$*0.00*
QTY: 50 Right Glass Retainer (1601402) *No Longer Available* +$*0.00*
QTY: 51 Left Insert [Needed for Models prior to 1/86] (1301784) *No Longer Available* +$*0.00*
QTY: 53 Glass Clips [Long] (1601395) +$11.18
QTY: 54 Glass Gasket with Wire (5002801) +$60.42
QTY: 55 Hardware Package (5002803) *No Longer Available* +$*0.00*
QTY: 58 Clip Screws [10 per package] (1200980-10) +$24.52
QTY: 60 Glass [1 Piece] [2 per unit, each sold separately] (1401136) +$236.95
QTY: 61 Frame (1301418) +$183.78
QTY: 62 Owners Manual [hard copy] [Resolute III V2 9-21] (OMHC-VC) +$9.99
QTY: 63 Owners Manual [electronic copy] [Resolute III V2 9-21] (OMEL-VC) +$0.00
|
