Includes Models: RHEDV42RN, RHEDV42RP, RHEDV42TN, RHEDV42TP, RHEDV42RFN, RHEDV42RFP
Item Description (Part Number)
QTY: 1 Log Set Complete (10000206) +$Call to Order
QTY: 1A Front Ember Log (SR1) +$Call to Order
QTY: 1B Left Front Log (SR2) +$67.88
QTY: 1C Right Front Log (SR3) +$70.67
QTY: 1D Rear Log (SR4) +$Call to Order
QTY: 1E Left Top Log (SR5) +$Call to Order
QTY: 1F Right Top Log (SR6) +$Call to Order
QTY: 2 Lava Rock ~Old Part #s 10001454, 00F0540~ (SRV00F0540) +$45.67
QTY: 3 Burner Lava Rock (57897K) +$37.43
QTY: 4A Burner with Tiles Natural Gas (10000954) +$Call to Order
QTY: 4B Burner with Tiles Propane (10000955) +$Call to Order
QTY: 5 Ceramic Tile Single ~Old Part #57803~ (SRV57803) recommend replacing a new Gasket. the Gasket will need to be custom cut. Gasket Part #CFPAP 1/2-48-65-1. +$34.49
QTY: 6A Orifice Front Burner Natural Gas (20007347) +$40.88
QTY: 6B Orifice Front Burner Propane (Call for Part #) +$Call to Order
QTY: 7A Orifice Main Burner Natural Gas (Call for Part #) +$Call to Order
QTY: 7B Orifice Main Burner Propane (Call for Part #) +$Call to Order
QTY: 8A Orifice Pilot SIT Natural Gas ~Old Part # 54273, 32D2051~ (32D2051K) +$34.49
QTY: 8B Orifice Pilot SIT Propane (54272) +$41.41
QTY: 9A Orifice Pilot PSE Natural Gas (10001822) +$14.31
QTY: 9B Orifice Pilot PSE Propane (10001823) +$20.52
QTY: 10A 3-Way Top Convertible Pilot Assembly NG-SIT [includes: Thermopile, Thermocouple, Pilot, Pilot Tube & Electrode with Wire] (Call for Part #) +$Call to Order
QTY: 10B-Pilot Assembly 3-Way Propane Gas [SIT] ~Old Part #10002265~ (SRV10002265) +$157.17
QTY: 11A Pilot Assembly PSE Natural Gas [Honeywell] (10001741) +$266.71
QTY: 11B Pilot Assembly PSE Natural Gas [Honeywell] ~Old Part #10001742, 20001116~ (20001116A) +$285.52
QTY: 12 Pilot SIT [this new Part # Only fits new Style Pilot Assembly If You have an Original Pilot Assembly, You must get a new Style Pilot Assembly] ~Old Part #10001295~ (10002385) +$42.38
QTY: 13 Pilot PSE with Cable & Electrode (10001824) *No Longer Available* [can Sub A Pilot Assembly Part #s 20001116 or 20001115] +$Call to Order
QTY: 14 Pilot Tube with Fittings SIT (26D0665) +$36.04
QTY: 15 Manifold Tubing with Fittings (57318) +$75.32
QTY: 16 Thermocouple 24 Inches SIT Millivolt ~Old Part #24D0808~ (SRV24D0808) +$48.46
QTY: 17 Thermocouple PSE ~Old Part # 30000313~ (10001825) +$47.07
QTY: 18 Thermopile 24 Inches ~Old Part #26D0566~ (SRV26D0566) +$130.62
QTY: 19 Electrode Igniter with Cable SIT (10001297) +$33.02
QTY: 20 Igniter Piezo SIT ~Old Part #057958~ (057958A) +$37.43
QTY: 21 Igniter Piezo Honeywell (2000062) +$Call to Order
QTY: 22A Gas Valve SIT-MV-Hi/Low Natural Gas ~Old Part #37D0117, 37D0117A~ (230-0710) +$360.54
QTY: 22B Gas Valve SIT-MV-Hi/Low Propane ~Old Part #37D0118~ (SRV37D0118) +$270.74
QTY: 23A Valve Honeywell VC 8420E 2038 Natural Gas ~Old Part#10001782~RN 272 Honeywell Valve to SIT Retrofit Valve (10008800) +$282.84
QTY: 23B Valve Honeywell VC 8420E 2038 Propane ~Old Part#10001759~RP 273 Honeywell Valve to SIT Retrofit Valve (10008893) +$300.25
QTY: 24A Valve EUROSIT 630 TN (53448) +$398.44
QTY: 24B Valve EUROSIT 630 TP (53446) *No Longer Available* +$*0.00*
QTY: 25 Fan & Bracket Sub FK12 & reuse Bracket ~Old Part #54103~ (FK24) +$583.05
QTY: 26 Electric Cord [6 ft] ~Old Part #s 51865, 26D0619~ (SRV26D0619) +$60.89
QTY: 27 Fan Temperature Sensor ~Old Part #51704~ (SRV51704) +$45.67
QTY: 28 Speed Control ~Old Part #51738 (SRV51738) +$90.09
QTY: 29 Speed Control Knob (51882) +$26.61
QTY: 30 Glass with Gasket (54234) +$Call to Order
QTY: 31 Gasket Glass [12ft per package] ~Old Part #s 57316, 10000992, 10000992K ~ (10000992K/12) +$141.80
QTY: 32 Frame Window (10000960) *No Longer Available* +$*0.00*
QTY: 33 Remote Switch ~Old Part # 53606~ (30000874) +$12.84
QTY: 34 Remote Switch Wire Harness (10002582) +$33.02
QTY: 35 Ceramic Refractory Kit (10000996) +$Call to Order
QTY: 36 Clamp Frame Window (10000949) +$14.92
QTY: 37A RFN Valve Natural Gas [RFN Honeywell to RCSITEA Retrofit] [includes: Valve, Valve Stepper, Pilot Assembly, Remote, Control Center & Regulator] ~Old Part #20003719~ (20301208) +$998.82
QTY: 37B RFP Valve Propane [Honeywell Comfort Control Gas Valve to SIT Retrofit Gas Valve] [includes: Valve, Valve Stepper, Pilot Assembly, Remote, Control Center & Regulator] ~Old Part #20003720~ (20301209) +$998.82
QTY: 38 RF Pilot Assembly Natural Gas (20002266) +$327.05
QTY: 39 RF Pilot Assembly [NG Gas] [this Pilot Assembly Only comes NG, use Part #20002266, must Add 20000907 Propane Orifice to convert to LP](20002268) *No Longer Available* +$*0.00*
QTY: 40 Transmitter Honeywell [Remote] [Can upgrade to 20301208 Natural Gas or 20301209 LP] (20002047) *No Longer Available* +$*0.00*
QTY: 41 Transmitter Natural Gas [Honeywell Comfort Control Gas Valve to SIT Retrofit Gas Valve] [includes: Valve, Valve Stepper, Pilot Assembly, Remote, Control Center & Regulator] (20301208) +$998.82
QTY: 42 Transmitter Propane Gas [Honeywell Comfort Control Gas Valve to SIT Retrofit Gas Valve] [includes: Valve, Valve Stepper, Pilot Assembly, Remote, Control Center & Regulator] (20301209) +$998.82
QTY: 43 Thermopile PSE for RF Pilots ~Old Part #s 20002400, 26D0566~ (SRV26D0566) +$130.62
QTY: 44 Orifice Pilot Hood-NG-PSE Honeywell [FITS between the Pilot Assembly and the Pilot Tube] (20000908) +$15.06
QTY: 45 Orifice Pilot Hood-LP-PSE Honeywell [FITS between the Pilot Assembly and the Pilot Tube] (20000907) +$29.06
|
