Vermont Castings and Majestic Stoves and Fireplaces

Sequoia Stove  #455C

Sequoia Stove


Item# 455C     Price: $0.00

Item Description (Part Number)

QTY: 1 ASH DOOR (7000820) +$72.31

QTY: 2 BACK (7000822) +$Call to Order

QTY: 3 BAFFLE (7000837) +$57.82

QTY: 4 BOTTOM (7000824) +$Call to Order

QTY: 5 BYPASS GATE (7000806) +$Call to Order

QTY: 6 BYPASS GATE CONNECTOR (REP 0523) (7000512A) +$Call to Order

QTY: 7 BYPASS GATE CRANK ASSEMBLY (700838A) +$Call to Order

QTY: 8 BYPASS GATE SIDE SUPPORT (7000514) +$Call to Order

QTY: 9 COAL STRAINER (7000830) +$Call to Order

QTY: 10 COOK TOP (7000818) +$Call to Order

QTY: 11 COOK TOP SECURING ROD (7000827) +$Call to Order

QTY: 29a-229a- Pilot orifice, SIT Top Convertible Nat ~Old Part Number 10002268~ (37D0022) +$51.22

QTY: 29b-229b- Pilot orifice, SIT Top convertible Prop ~Old Part Number 10002269~ (37D0023) +$Call to Order

QTY: 12b DOOR SHAFT (700G809) +$17.84

QTY: 13 FAN PLATE REAR (7000831) +$35.69

QTY: 14 FAN COVER BRASS (1406063) +$64.42

QTY: 15 FIXED CENTER GRATE (7000802) +$53.86

QTY: 16 FLUE COLLAR (7000400) +$Call to Order

QTY: 17 FRONT (7000804) +$Call to Order

QTY: 18 FRONT DOOR SEQUOIA (7001002) +$127.54

QTY: 18a GLASS RETAINER (7001012) +$10.24

QTY: 18b DOOR GLASS (7001011) +$195.49

QTY: 18c PAN HD PHILLIP 1/4-20 X 3/8IN -BLK (1200993) +$10.24

QTY: 19 FRONT GRATE (7000936) +$Call to Order

QTY: 20 GRATE BACK (7000808) +$57.82

QTY: 21 GRATE FRAME (7000807) +$Call to Order

QTY: 22 FALLAWAY HANDLE COMPLETE (000A902) +$87.27

QTY: 22a SPRING FOR HANDLE (70000G3) +$10.24

QTY: 23 HEARTH (7000823) +$Call to Order

QTY: 24 INLET PLATE (7000832) +$Call to Order

QTY: 25 INNER BACK (7000812) +$Call to Order

QTY: 26 INNER BOTTOM (7000805) +$Call to Order

QTY: 27 INNER TOP (7000857) +$Call to Order

QTY: 28 INNER TOP CHANNEL (7000858) +$Call to Order

QTY: 29 LEFT COAL GRATE SIDE (7000937) +$Call to Order

QTY: 30 LEFT SIDE (7000816) +$Call to Order

QTY: 31 LEFT SIDE DOOR (7000817) +$Call to Order

QTY: 32 LEG (7000829) +$39.65

QTY: 33 RIGHT SIDE COAL GRATE (7000938) +$Call to Order

QTY: 34 RIGHT SIDE (7000813) +$Call to Order

QTY: 35 ROCKER (SHAKER) GRATE (7000801) +$63.56

QTY: 36 SHAKER GRATE CAP ASSEMBLY (70000G2) +$14.78

QTY: 37 SHAKER GRATE COVER (7000803) +$28.09

QTY: 38 SHAKER GRATE TOOL (7000835) +$28.09

QTY: 39 SIDE HALF WALL [RIGHT] (7000800) +$Call to Order

QTY: 40 TOP 1 (7000825) +$Call to Order

QTY: 41 AIR DISTRIBOTOR [ROUND TUBE] (700G814) +$Call to Order

QTY: 42 ASH PAN (700G802) +$96.08

QTY: 43 BOTTOM HEAT SHIELD (700G810) +$Call to Order

QTY: 43a CS HEX HD 1/4-20 X 1 1/4IN FLAT HEAD - BLK (1201378) +$10.24

QTY: 43b CS HEX HD 1/4-20 X 5/8IN - BLK (1201372) +$10.65

QTY: 43c WASHER FLT 1/4-Z X 06T 10 (742O) +$Call to Order

QTY: 44 BRASS WINDOW TRIM (7000839) +$117.80

QTY: 45 BYPASS CONNECTOR CLIP (1601036) +$28.09

QTY: 46 BYPASS OPERATING ROD (700G805) +$Call to Order

QTY: 47 7IN CATALYST - MUST ALSO ORDER (1203535) +$Call to Order

QTY: N/S INTERAM GASKET (1203535) +$Call to Order

QTY: 48 CATALYST PROBE THERMOMETER [1IN SHAFT] (7000TH3) +$69.79

QTY: 49 COOKTOP SLEEVE (700G812) +$Call to Order

QTY: 50 FIRESCREEN (700G803) +$135.45

QTY: 51 FRONT DOOR HINGE (700G806) +$39.65

QTY: 52 GLASS 15_IN X 8IN (7001011) +$Call to Order

QTY: 53 GLASS FRAME (700G800) +$Call to Order

QTY: 54 GLASS SPACER FRAME (700G801) +$35.69

QTY: 55 HEAT SHIELD BRACKET (7000115) +$Call to Order

QTY: 56 INLET SCREEN (700G811) +$Call to Order

QTY: 57 BRASS DIAL LARGE (7000011) +$57.82

QTY: 58 BRASS DIAL SMALL (7000521) +$47.25

QTY: 59 SIDE DOOR HINGE PLATE (700G808) +$28.09

QTY: 60 FRONT DOOR GASKET (7000910) +$Call to Order

QTY: 61 ASH DOOR HINGE 5IN (1201837) +$17.84

QTY: 62 PEDESTAL (7000855) +$Call to Order

QTY: 63 AIR DIFFUSER PLATE (7000945) +$Call to Order

QTY: 64 REAR HEAT SHIELD ASSEMBLY (HS455) +$Call to Order

QTY: 65 REAR HEAT SHIELD WNGS (HS455W) +$Call to Order

QTY: 66 BRASS TRIM (000A527) +$Call to Order

QTY: 67 FAN KIT (0009973) +$251.68

QTY: 68 GLASS GASKET 4.5 EACH GLASS (30000776) +$10.65

Related Items:
  •  Stove Gasket Kit
  • AVAILABLE IN:
    QTY:

    Continue Shopping

    Customers who bought this product also purchased...
    Sequoia Gasket Kit
    $99.00
