Dutchwest Small Cast Non Catalytic Stove #2477

Dutchwest Small Cast Non Catalytic Stove


Item# 2477     Price: $0.00

Item Description (Part Number)

QTY: 1- BOTTOM (30002174) +$275.27

QTY: 2- INNER BOTTOM (30002175) +$184.17

QTY: 3- INNER BACK ~Old part #30002295~ (30002295A) +$243.12

QTY: 4- RIGHT SIDE (30002082) +$157.37

QTY: 5- LEFT SIDE (30002083) +$135.77

QTY: 6- OUTSIDE AIR BRACKET (30002205) +$48.76

QTY: 30 FOUNTAIN [WILL RECOMEND GET FOUNTAIN GASKET KIT] ~Old Part # 30002100~ (0000122) +$477.58

QTY: 30A-EVERBURN [FOUNTAIN] GASKET KIT (0003447) +$135.77

QTY: 8- BRACKET BRICK SUPPORT (30004465) +$23.49

QTY: 9- SHOE REFRACTORY (30002101) +$311.45

QTY: SHOE GASKET [DOES NOT COME W/REFRACTORY] (30002286) +$11.01

QTY: 10- LOWER FIREBACK REFRACTORY (30002307) +$343.60

QTY: 11- UPPER FIREBACK REFRACTORY (30002308) +$285.99

QTY: 12- RETAINER LOWER RIGHT (30002303) +$38.98

QTY: 12A- RETAINER LOWER LEFT (30002337) +$38.98

QTY: 13- RIGHT END INSULATION (30002209) +$50.16

QTY: 14- RIGHT END REFRACTORY (30002213) +$132.97

QTY: 16- PRIMARY AIR FLAP W/NICKEL BALL (30002734) +$82.66

QTY: 17- INNER TOP (30002300) +$210.96

QTY: 18- FIREBACK RETAINER (30002304) +$58.02

QTY: 19- DAMPER (7000954) +$44.57

QTY: 20- DAMPER ADJUSTER ~Old part #7000950~ (7000950A) +$65.01

QTY: 20A- DAMPER ADJUSTER HARWARE KIT (7000950H) +$17.98

QTY: 21- DAMPER CRANK (7000951) +$45.96

QTY: 22- DAMPER OPERATING ROD (30002311) +$23.49

QTY: 23- ASH DOOR (30002301) +$85.46

QTY: 24- ASH LIP (30002302) +$72.88

QTY: 25- FRONT DOOR (30002178) +$106.42

QTY: 26- LOAD DOOR INSULATION ~ OLD PART # 30002210~ (30004725) +$290.01

QTY: 27- LOAD DOOR REFRACTORY UPGRADED COMES WITH INSULATION [30002210] TO NEW REFRACTORY PART NUMBER(30004725) +$290.01

QTY: 28-FALLAWAY HANDLE W/GOLD NUB (0005854) +$62.22

QTY: 28-BLACK WOOD HANDLE W/LIFTER NICKEL (30002787) +$33.75

QTY: 29- LOAD DOOR II [WHEN USED ON STOVES BUILT PRE JUNE05 MUST ALSO REPLACE REFRACTORY AND INSULATION] (30002439) +$119.00

QTY: 30- GRATE (30002092) +$106.42

QTY: 31- DAMPER HANDLE W/SET SCREW (5004267) +$66.41

QTY: 31A- DAMPER HANDLE W/SET SCREW NICKEL (5004265) +$50.16

QTY: 32 TOP ~Old part #30002299~ (30002299A) +$228.38

QTY: 33- FLUE COLLAR (7000969) +$88.25

QTY: 34- OUTER BACK (30002310) +$283.31

QTY: 35- ASH PAN (7000G79) +$72.88

QTY: 36- ASH DOOR HANDLE W/SHAFT (5004271) +$66.41

QTY: 36A- ASH DOOR HANDLE W/SHAFT NICKEL (5004237) +$56.63

QTY: 37- GLASS (30002156) +$247.14

QTY: 38- GLASS RETAINER(30002146) +$11.01

QTY: 38A- SCREW (1200996) +$10.65

QTY: 39- LEG ~Old part #30002086~ (30002086A) +$40.37

QTY: 40- PAWL ASSEMBLY 3/4IN SHORT ADJUSTER ASH DOOR(30002362) +$11.01

QTY: 41- FRONT & LOAD DOOR HANDLE W/SHAFT [FRONT AND SIDE NUB W/SHAFT](5004273) +$56.63

QTY: 41A- FRONT & LOAD DOOR HANDLE W/SHAFT NICKEL [FRONT AND SIDE NUB W/ SHAFT](5004245) +$56.63

QTY: 42- BOTTOM HEAT SHIELD (30002312) +$67.81

QTY: 43- PRIMARY AIR MANIFOLD (30002176) +$99.43

QTY: 44- FRONT (30002173) +$219.00

QTY: 45- ANDIRON (30002383) +$23.13

QTY: 46- BRACKET RHEOSTAT NO LONGER AVAILIBLE (30002216)0:Call to Order +$23.49

QTY: 47- PAWL ASSEMBLY 5004025 (30005157) +$48.76

QTY: 47AA-ALLEN WRENCH FOR PAWL ASSEMBLY (1205116) +$11.01

QTY: 47A-JAM NUT (1203290) +$10.65

QTY: 48- NICKEL KNOB FOR PRIMARY AIR FLAP (30002729) +$11.01

QTY: 49- DOOR PIN (1201836) +$11.01

QTY: 50- BLOWER [FAN] (FK26) +$397.95
