Vermont Castings and Majestic Stoves and Fireplaces

Consolidated Dutchwest-FA224ACL #224ACL-APLUS-1988-1989-Canadian

Consolidated Dutchwest-FA224ACL


Item# 224ACL-APLUS-1988-1989-Canadian     Price: $0.00

Item Description (Part Number)

QTY: 1-ASH BIN (7000777) NO LONGER AVAILABLE +$Call to Order

QTY: 2-ASH DOOR (7000779) NO LONGER AVAILABLE +$Call to Order

QTY: 3-ASH DOOR FRAME (7000778) NO LONGER AVAILABLE +$Call to Order

QTY: 4-BACK (7000772) NO LONGER AVAILABLE +$Call to Order

QTY: 5-BAFFLE (7000276) +$39.65

QTY: 6-BOTTOM (7000775) NO LONGER AVAILABLE +$Call to Order

QTY: 7-BY-PASS GATE (7000877) +$10.24

QTY: 8-BY-PASS GATE CONNECTOR (7000523) & SUBSTITUTE 700512A NO LONGER AVAILABLE +$68.53

QTY: 9-BY-PASS GATE CRANK (700512A) +$102.96

QTY: 10-BY-PASS GATE SUPPORT (7000514) NO LONGER AVAILABLE +$Call to Order

QTY: 11-COMBUSTOR CHAMBER (7000274) +$58.87

QTY: 12-COOKTOP (7000711) +$Call to Order

QTY: 13-DOOR LATCH KIT (0000838) +$39.65

QTY: 14-DOOR PANEL (7000007) NO LONGER AVAILABLE +$Call to Order

QTY: 15-FIXED GRATE SECTION-12 _BD_94 LONG (7000342) +$171.60

QTY: 16-FLUE COLLAR (7000969) +$69.79

QTY: 17-FRONT COAL GRATE (7000550) +$89.00

QTY: 18-FRONT (7000776) NO LONGER AVAILABLE +$Call to Order

QTY: 19-GRATE BACK (7000551) +$65.00

QTY: 20-GRATE FRAME (7000365) NO LONGER AVAILABLE +$171.60

QTY: 21-HEARTH (7000369) NO LONGER AVAILABLE +$Call to Order

QTY: 22-INNER TOP (7000915) NO LONGER AVAILABLE +$Call to Order

QTY: 23-INNER TOP CHANNEL (7000914) NO LONGER AVAILABLE +$Call to Order

QTY: 24-LEFT DOOR (7000728) NO LONGER AVAILABLE +$Call to Order

QTY: 25-LEFT SIDE GRATE (7000346) +$58.77

QTY: 26-LEG[8 +$25.43

QTY: 27-RIGHT DOOR (7000729) NO LONGER AVAILABLE +$Call to Order

QTY: 28-RIGHT SIDE (7000771) NO LONGER AVAILABLE +$Call to Order

QTY: 29-RIGHT SIDE GRATE (7000344) +$58.77

QTY: 30-ROCKER GRATE (7000341) +$57.02

QTY: 31-SHAKER GRATE CAP ASSEMBLY (70000G2) +$14.78

QTY: 32-SHAKER GRATE COVER [7000726] & SUBSTITUTE (7001020) +$63.56

QTY: 33-SIDE (????) NO LONGER AVAILABLE +$Call to Order

QTY: 34-SIDE DOOR [7000709] (7001020) +$63.56

QTY: 35-SIDE HALF WALL (7000029) +$131.45

QTY: 36-STRAINER (7000275) +$45.79

QTY: 37-TOP (7000773) NO LONGER AVAILABLE +$Call to Order

NON-CAST PARTS USES SEQUOIA STYLE DOOR LATCHES

Item Description (Part Number)

QTY: 38-FRONT (7002777) NO LONGER AVAILABLE +$Call to Order

QTY: 39- FRONT WITH DOORS (700777S) NO LONGER AVAILABLE +$Call to Order

QTY: 40- LEFT SIDE (7002771) NO LONGER AVAILABLE +$Call to Order

QTY: 41- LEFT SIDE WITH DOOR (700771S) NO LONGER AVAILABLE +$Call to Order

QTY: 42- AIR TUBE (700G202) +$67.50

QTY: 43- ASHPAN (7000G79) +$57.82

QTY: 44- BRASS DIAL DAMPER 0000844 (7000011) +$57.82

QTY: 45- BRASS DIAL DAMPER COMBUSTOR (7000521) +$47.25

QTY: BRASS HANDLE (000A902) +$87.27

QTY: 47- BRASS NAME PLATE (7000044) NO LONGER AVAILABLE +$Call to Order

QTY: 48- BYPASS GATE OPERATING ROD (700G118) NO LONGER AVAILABLE +$Call to Order

QTY: 49- CATALYST PROBE THERMOMETER (7000TH3) +$69.79

QTY: 50- CATALYTIC COMBUSTOR (000CB56) +$267.07

QTY: 51- DOOR SHAFT INSERT THREAD REPAIR (7000G13) NO LONGER AVAILABLE +$Call to Order

QTY: 52- DOOR STEM THREADED (7000G14) +$9.31

QTY: 53- FIRESCREEN (7000G70) +$44.05

QTY: 54-GLASS FRAME (700822F) +$45.00

QTY: 55- GLASS (7001106) +$73.89

QTY: 56- HANDLE EXTENSION (0000842) NO LONGER AVAILABLE +$Call to Order

QTY: 57- HANDLE SPRING (70000G3) +$10.24

QTY: 58- HEAT SHIELD (70000I1) NO LONGER AVAILABLE +$Call to Order

QTY: 59- HEAT SHIELD BACK (70000I3) NO LONGER AVAILABLE +$Call to Order

QTY: 60- HEAT SHIELD BRACKET BOTTOM (70000I8) NO LONGER AVAILABLE +$Call to Order

QTY: 61- HEAT SHIELD BRACKET REAR (70000I4) NO LONGER AVAILABLE +$Call to Order

QTY: 62- HEAT SHIELD MIDDLE (70000I2) NO LONGER AVAILABLE +$Call to Order

QTY: 63- OUTLET SCREEN (7000G450) NO LONGER AVAILABLE +$Call to Order

QTY: 64- SHAKER GRATE TOOL (7000348) +$14.78

QTY: 65- TORSION BAR CLIP (1601036) +$28.09

QTY: 66- WALL BRACKET (7000G53) NO LONGER AVAILABLE +$Call to Order

Dutchwest Hardware

Item Description (Part Number)

QTY: 4MM X 14MM PHILLIPS TRS HD SHEET METAL SCREW [STOVEPIPE TO FLUE COLLAR] (1202089) +$Call to Order

QTY: 8MM X 1 1/4 PHIL TRUS HD WD SCREW [WALL BRACKET] (1201301) +$Call to Order

QTY: 1/4_20 X 1/2 HEX HEAD CAP SCREW [HEAT SHIELD, BYPASS CONNECTOR CLIP, SEQUOIA GLASS FRAME] (1201338) +$10.24

QTY: _BC-20 HEX NUT [HEAT SHIELD] (1203210) +$10.24

QTY: 1/4_20 X 3/4 HEAD SCREW [FLUE COLLAR, HEARTH PLATE, SEQUOIA SIDES] (1200881) +$10.24

QTY: 1/4_20 X 1-1/4 HEX HD CAP SCR [BOTTOM, BACK, LEG BOLT] (1201378) +$10.24

QTY: 1/4 X 7/8 FLAT WASHER [BOTTOM, BACK, FRONT, TOP, LEG BOLT] (1202470) +$10.24

QTY: 1/4_20 X 3/4 HEX HEAD CAP SCREW [SIDE PART, REAR PART, BYPASS GATE SIDE SUPPORT, GRATE BACK SIDE HALF WALL, BOOT PLATE, SEQUOIA INNER BACK & FLUE COLLAR] (1201374) +$10.65

QTY: 1/4 STD FLAT WASHER [SIDE & REAR PART, BACK, BAFFLE, TOP, FRONT DOOR, BOOT PLATE, SEQUOIA INNER BACK, SIDES, FRONT, GRATE BACK, HINGES](1202474) +$10.24

QTY: 1/4_20 X 5/8 PHIL FL HEAD MACHINE SCREW [BACK COVER PANEL] (1200865) +$10.24

QTY: 1/4_20 X 5/8 HEX HEAD CAP SCREW [BACK, INLET PLATE, SEQUOIA HINGES & HEARTH (1201372) +$10.65

QTY: 1/4_20 X 1-1/2 CRS STUD [BACK, FRONT, TOP] (1204214) +$10.24

QTY: 1/2-20 HEX NUT [BACK, FRONT, TOP, SIDES TO BOTTOM, A PLUS ASH DOOR FRAME] (1203210) +$10.24

QTY: HINGE PIN (1201836) +$10.24

QTY: SEQUOIA ASH DOOR HINGE PIN (1201837) +$17.84

QTY: 1/4_20 X 1 HEX HEAD CAP SCREW [BAFFLE, A PLUS ASH BIN] (1201326) +$10.24

QTY: 1/4_20 X 1/2 HEX HEAD CAP SCREW [DOOR PANEL, TORSION BAR CLIP] (1201338) +$10.24

QTY: 3/8-16 HEX JAM NUT [DOOR SHAFT] (1203157) +$10.24

QTY: 1/4 X 1-1/4 FENDER WASHER [ROCKER GRATE] (1202527) +$10.24

QTY: 1/4_20 X 1-1/2 PHIL FL HD SCREW [ROCKER GRATE] (1200815) +$10.24

QTY: WING NUT 1/4_20 [ROCKER GRATE] (1203110) +$10.24

QTY: 10-24 X 1/2 HEX HEAD CAP SCREW [ROCKER GRATE] (1201322) +$10.24

QTY: 3/8-16 X 1-1/2 HEX HEAD CAP SCREW [BYPASS GRATE CONNECTOR] (1201456) +$10.24

QTY: 3/8-16 HEX TOP LOCK JAM NUT [BYPASS GRATE CONNECTOR] (1203290) +$10.24

QTY: 1/4_20 X 7/8_94 10MM HEX HD CAP SCREW [TOP, SIDE FOR SHROUD] (1201375) +$8.01

QTY: 7/16 X 5/8 LOCK WASHER [BRASS DIAL] (1202463) +$8.01

QTY: 3/8-16 NARROW HEX NUT [BRASS DIAL] (1203161) +$10.24

QTY: 1/4_20 X 1 3/4 PH FL HD [SIDES TO BOTTOM, A PLUS ASHDOOR FRAME] (1200830) +$10.24

QTY: 1/4 X 3/4 WASHER [GRATEBACK] (1202469) +$10.65

QTY: 1/4_20 X 2 PIN HEX HD CS [INNER TOP CHANNEL, SEQUOIA BAFFLE] (1201392) +$10.24

QTY: 1/4_20 X 1 1/4 STUD [SEQUOIA BACK] (1204212) +$10.24

QTY: 1/4_20 X 2 PHILLIPS FLAT HD MS [SEQUOIA AIR DISTRIBUTOR] (1200848) +$10.24

QTY: 1/4_20 X 1 1/4 PHILLIPS FLAT HD SCREW [SEQUOIA SHAKER GRATE COVER, INLET PLATE] (1200811) +$10.24

QTY: 1/4_20 1 PHILLIPS FLAT HEAD SCREW [SEQUOIA TOP] (1200809) +$4.96

QTY: 1/4 FLAT WASHER [SEQUOIA SIDE HINGE] (1202473) +$10.24

QTY: 5/16-18 X 5/16 SOCKET SET SCREW [SEQUOIA DOOR CATCH] (1200563) +$10.24

QTY: 1/4 X .5 OD FLAT WASHER [SEQUOIA HEARTH] (1202475) +$10.24

QTY: 1/4_20 X 1 HEX HD CAP SCREW [SEQUOIA LEG BOLT] (1201376) +$10.24
QTY:
